Smart Grid Integration
Smart Grid Integration
- <100ms fault response
- <2% curtailment through forecasting
- Dual-mode grid-forming/grid-following
Overview
Technical Specifications
Send Message
Overview
Our grid integration solutions bridge renewable generation with utility networks through:
1. Advanced Power Electronics
Hybrid inverters with 100% reactive power capability
Dynamic VAR compensation (STATCOM/SVC)
2. Predictive Load Management
AI-based forecasting (95% day-ahead accuracy)
Automatic generation control (AGC) integration
3. Compliance Expertise
IEEE 1547-2018, UL 1741 SB
CAISO Rule 21, ERCOT NPRR 863
Case Study: 150MW solar farm achieving 99.98% availability despite 40% renewable penetration.
Technical Specifications
| Core Components | |
|---|---|
| Inverter Type | Grid-forming + Q-V droop control |
| Voltage Regulation | ±5% bandwidth (ANSI C84.1) |
| Synchronization Speed | <2 cycles (IEEE 1547) |
| Performance Metrics | |
| Total Harmonic Distortion (THD) | <3% at full load |
| Ramp Rate | 10%/minute adjustability |
| Islanding Detection | <0.5 seconds |
| Certifications | |
| |
Additional Features
- 100% reactive power capability
- Dynamic VAR compensation (STATCOM/SVC)
- AI-based forecasting (95% day-ahead accuracy)
- Automatic Generation Control (AGC) integration
